C Programming Lab Manual – 70

Write a C program for Dijkstra Algorithm in a Graph.

Dijkstra(G,s):
	 for each vertex u ∈ G.V - {s}
	 u.d = ∞
	 u.pred = null
	 u.done = false
	 s.d = 0
	Q = G.V
	 while Q ≠ ∅
	 u = Q.extractMin()
	 u.done = true
	 for each v ∈ G.Adj[u]
	 Relax(u,v)
Relax(G,u,v):
	if u.d + G.edge(u,v).w < v.d
	 v.d = u.d + G.edge(u,v).w
	v.pred = u

#include <stdio.h>
#include <stdlib.h>
#include <limits.h>

#define MAX_VERTICES 1000

struct Edge {
    int v;
    int weight;
    struct Edge *next;
};

struct Vertex {
    int d;
    int pred;
    int done;
    struct Edge *adjList;
};

struct Vertex vertices[MAX_VERTICES];
int numVertices;

void relax(int u, int v, int weight) {
    if (vertices[u].d + weight < vertices[v].d) {
        vertices[v].d = vertices[u].d + weight;
        vertices[v].pred = u;
    }
}

int extractMin(int Q[]) {
    int min = INT_MAX;
    int minIndex = -1;

    for (int i = 0; i < numVertices; i++) {
        if (!vertices[i].done && vertices[i].d < min) {
            min = vertices[i].d;
            minIndex = i;
        }
    }

    return minIndex;
}

void dijkstra(int source) {
    for (int u = 0; u < numVertices; u++) {
        vertices[u].d = INT_MAX;
        vertices[u].pred = -1;
        vertices[u].done = 0;
    }

    vertices[source].d = 0;

    int Q[MAX_VERTICES];
    for (int i = 0; i < numVertices; i++) {
        Q[i] = i;
    }

    while (1) {
        int u = extractMin(Q);
        if (u == -1) break;

        vertices[u].done = 1;

        struct Edge *edge = vertices[u].adjList;
        while (edge != NULL) {
            relax(u, edge->v, edge->weight);
            edge = edge->next;
        }
    }
}

int main() {
    int numEdges;
    printf("Enter the number of vertices and edges: ");
    scanf("%d %d", &numVertices, &numEdges);

    for (int i = 0; i < numVertices; i++) {
        vertices[i].adjList = NULL;
    }

    printf("Enter edge information (u v weight):\n");
    for (int i = 0; i < numEdges; i++) {
        int u, v, weight;
        scanf("%d %d %d", &u, &v, &weight);

        struct Edge *newEdge = malloc(sizeof(struct Edge));
        newEdge->v = v;
        newEdge->weight = weight;
        newEdge->next = vertices[u].adjList;
        vertices[u].adjList = newEdge;
    }

    int source;
    printf("Enter the source vertex: ");
    scanf("%d", &source);

    dijkstra(source);

    printf("Shortest paths from source vertex %d:\n", source);
    for (int i = 0; i < numVertices; i++) {
        if (i != source) {
            printf("Vertex %d: Distance = %d, Pred = %d\n", i, vertices[i].d, vertices[i].pred);
        }
    }

    return 0;
}

Enter the number of vertices and edges: 5 7
Enter edge information (u v weight):
0 1 4
0 2 1
1 2 3
1 3 2
2 3 4
2 4 5
3 4 1
Enter the source vertex: 0
Shortest paths from source vertex 0:
Vertex 1: Distance = 4, Pred = 0
Vertex 2: Distance = 1, Pred = 0
Vertex 3: Distance = 5, Pred = 2
Vertex 4: Distance = 6, Pred = 2

C Programming Lab Manual – 69

Write a C program for Kruskal’s Minimum Spanning Tree (MST) Algorithm in a Graph.

MST-Kruskal(G)
	    for each v ∈ G.V
 Make-Set(v)
	   for each (u,v) by weight
if Find-Set(u) ≠ Find-Set(v)
Union(u,v)
(u,v).inMST = True

#include <stdio.h>
#include <stdlib.h>

#define MAX_VERTICES 1000

struct Edge {
    int u, v, weight;
};

struct Subset {
    int parent;
    int rank;
};

struct Edge edges[MAX_VERTICES];
struct Subset subsets[MAX_VERTICES];

int findSet(int i) {
    if (subsets[i].parent != i)
        subsets[i].parent = findSet(subsets[i].parent);
    return subsets[i].parent;
}

void unionSets(int x, int y) {
    int xRoot = findSet(x);
    int yRoot = findSet(y);

    if (subsets[xRoot].rank < subsets[yRoot].rank)
        subsets[xRoot].parent = yRoot;
    else if (subsets[xRoot].rank > subsets[yRoot].rank)
        subsets[yRoot].parent = xRoot;
    else {
        subsets[yRoot].parent = xRoot;
        subsets[xRoot].rank++;
    }
}

int compareEdges(const void *a, const void *b) {
    return ((struct Edge *)a)->weight - ((struct Edge *)b)->weight;
}

void kruskalMST(struct Edge graph[], int V, int E) {
    qsort(graph, E, sizeof(struct Edge), compareEdges);

    for (int v = 0; v < V; v++) {
        subsets[v].parent = v;
        subsets[v].rank = 0;
    }

    int mstEdges = 0;
    int mstWeight = 0;

    for (int e = 0; e < E; e++) {
        int u = graph[e].u;
        int v = graph[e].v;

        int uRoot = findSet(u);
        int vRoot = findSet(v);

        if (uRoot != vRoot) {
            unionSets(uRoot, vRoot);
            mstEdges++;
            mstWeight += graph[e].weight;
            printf("(%d, %d) in MST\n", u, v);
        }

        if (mstEdges == V - 1)
            break;
    }

    printf("MST Weight: %d\n", mstWeight);
}

int main() {
    int V, E;
    printf("Enter number of vertices and edges: ");
    scanf("%d %d", &V, &E);

    for (int i = 0; i < E; i++) {
        printf("Enter edge (u v weight): ");
        scanf("%d %d %d", &edges[i].u, &edges[i].v, &edges[i].weight);
    }

    kruskalMST(edges, V, E);

    return 0;
}

Enter number of vertices and edges: 4 5
Enter edge (u v weight):
1 2 2
1 3 3
2 3 1
2 4 4
3 4 5
Enter edge (u v weight): (2, 3) in MST
(1, 2) in MST
(2, 4) in MST
MST Weight: 7
